Atlas FM9SL 9,000 lb In Ground Full-Rise Lift - ATEATTD-FM9SL-FPD
Atlas 9,000 lb. In-Ground Scissor Lift
The Atlas FM9SL 9,000 lb. flush mounted scissor lift is the perfect choice for those service facilities that need to maximize the number of vehicle lifts per service area square foot. If you like the “clean floor look” for your service department (no above ground lifts), then the Atlas® FM9SL flush mounted scissor lift offers the perfect alternative. Unlike “old school in-ground” lifts, the flush mounted lift requires minimal excavation and the electric/hydraulic power unit is easily accessed during periodic maintenance.The flush mounted platforms offer no “above ground” obstruction and the platforms can be “driven over” from any direction so that a vehicle may be properly positioned in the tightest of spaces. The Atlas FM9SL has both front and rear platform extensions that can be used when lifting a long wheel base pick-up truck.As with any scissor lift that is completely open (no cross support bar in the front or rear to keep the platforms level), the operator must make sure that the vehicle’s frame is positioned at least 6 inches from the inside of the platform. If too much weight is positioned near the edges of the platform (closer than 6 inches from the inside edges), the platforms may become “pigeon toed” and damage may occur. We sell the Atlas scissor lift support bar kit to disperse the narrow frame weight over the entire platform lifting surface
Video
Features
9,000 lb. Capacity
Commercial Grade
Full Rise Lift
Adjustable Width
Platforms Extend, Both Ends
No above ground obstruction
CE Certified
Air-Operated Single Point Lock Release (External Air Supply Required)
Open Center Design
Separate Self-Contained Control Unit
Grease Zerk Fittings at each Hinge Point
Heavy Duty Rubber Lifting Blocks Included
Mounting Hardware Included
220volt/1phase Electric Operation (Requires a 30amp Breaker)
Specifications
| Atlas FM9SL Specifications |
|
| Lifting Capacity |
9,000 lbs. |
| Max Lifting Height Above Floor w/ Standard Lifting Blocks |
73 3/4" (6' 1 3/4") |
| Max Lifting Height Above Floor w/o Standard Lifting Blocks |
71" (5' 11") |
| Overall Length w/ Extensions out |
80" (6' 8") |
| Overall Length w/ Extensions in |
64" (5' 4") |
| Platform Width |
21 " |
| Platform Thickness |
4" |
| Minimum Lowered Height (In Ground) |
13" |
| Width Between Platforms |
Adjustable up to 31" |
| Air Requirement |
90-120 PS( |
| Power Unit |
220 volt +/- 5% (209-231volts) single (1) phase. A 30 amp breaker is required |
| Oil Requirement |
3-5 Gallons AW32 or AW46 (NOT INCLUDED |
Manual
Atlas FM9SL Manual
Atlas FM9SL Parts Breakdown
What our Expect Think
-
Full-Rise Capability: The Atlas FM9SL In Ground Lift offers a 9,000 lb capacity, providing full rise lifting, ideal for working on cars, trucks, and other heavy-duty vehicles.
-
In-Ground Design: The in-ground configuration saves space in your garage, creating a cleaner, more efficient workspace without any obstructions.
-
Durable & Long-Lasting: Constructed with high-quality steel and designed for heavy-duty performance, this lift is built to endure frequent and demanding use.
-
Smooth Operation: Equipped with a hydraulic system for smooth and reliable lifting, ensuring ease of use and fast operation.
-
Space Efficient: Its in-ground installation is perfect for garages with limited overhead space, offering a sleek solution without sacrificing power or performance.
Q&A
Q: What is the lifting capacity of the Atlas FM9SL?
A: The Atlas FM9SL has an impressive 9,000 lb lifting capacity, making it ideal for lifting heavier vehicles, such as trucks, SUVs, and larger cars.
Q: Is the FM9SL an in-ground lift?
A: Yes, the FM9SL is an in-ground full-rise lift, designed to be installed beneath the floor for a cleaner, more accessible lifting solution with no obstructions around the vehicle.
Q: How high does the Atlas FM9SL lift?
A: The FM9SL offers a full-rise feature, allowing vehicles to be lifted to the maximum height for complete undercarriage access and efficient vehicle maintenance.
Q: Can the FM9SL be used for both home and professional use?
A: Yes, the Atlas FM9SL is perfect for both home garages and professional workshops, thanks to its high lifting capacity and durable in-ground design.
Q: How is the FM9SL operated?
A: The lift is operated via a hydraulic system, providing smooth and efficient operation with a user-friendly control panel.
Q: Is the Atlas FM9SL easy to install?
A: While installation requires professional assistance due to its in-ground design, the FM9SL offers a long-lasting solution for garages and shops seeking high-performance vehicle lifting.
